• Designed for smooth operation, Plug and Play no settings required.
  • Protection : Thunder Lightning - anti static and anti - interference ability up to 6KV.
  • 2 Ports X 100 Mbps uplink Ethernet port (Extra Port to connect Internet / Existing Network).
  • 4 Ports X 100 Mbps downlink PoE (Power over Ethernet), every port supports MDI / MDX.
  • Standard : Meet IEEE802.3 , IEEE802.3u , IEEE802.3 af/ at standards, Support MID - Span & END - Span Devices.
  • One Key CCTV / VLAN mode (All Downlink Ports can communicate with uplink ports only , it makes system more secure).
  • Transmission Distance : Ethernet 0 ~ 100m.
  • The furthest transmission distance can be reach 250 Meters in CCTV & VLAN mode uplink port can reach 100m.
  • Operating status can be analyzed through corresponding LED indicators on front panel.
  • Ideal for multi-stream cameras that required high bandwidth.
  • Compatibility with network devices from other vendors.
  • MAC address auto-learning and auto-aging.
  • Metal case with desktop or wall-mounting design.
  • Built in Power Supply.
  • Auto detect power devices (PD).
  • Store and forward switching method.
  • Switching Capacity - 1.2Gbps.
  • Forwarding Rate - 0.89Mpps (Million Packets Per Second).
